x3.0_naip_average_diffusion0.10
max height 158 plates = 505.6 mm · open whole-mountain 3D view
run mauna-loa-kilauea-20261001T190940 · generator 0.1.0+3c1a604-dirty · catalog lego-1x1-2026-10-01 · status failed
· variant
max height 158 plates = 505.6 mm · open whole-mountain 3D view
| footprint | 2048.0 × 2048.0 mm (256 × 256 studs) |
|---|---|
| geographic area | 48.00 × 48.00 km, 187.5 m per stud, EPSG:26905 |
| datum | 192.3 m (raw DEM min 184.4 m) |
| summit | 4154.3 m stud-mean at stud [42, 138] (source max 4169.6 m) |
| relief above datum | 3962.0 m |
| meters per plate (1×) | 75.000 |
| max height x3.0 | 158 plates / 505.6 mm |
| LDraw 0 | 37791 studs |
| LDraw 72 | 12318 studs |
| LDraw 308 | 10210 studs |
| LDraw 272 | 1473 studs |
| LDraw 288 | 1000 studs |
| LDraw 28 | 950 studs |
| LDraw 70 | 799 studs |
| LDraw 85 | 470 studs |
| LDraw 84 | 247 studs |
| LDraw 19 | 139 studs |
| LDraw 297 | 54 studs |
| LDraw 371 | 30 studs |
| LDraw 330 | 16 studs |
| LDraw 326 | 14 studs |
| LDraw 15 | 8 studs |
| LDraw 92 | 7 studs |
| LDraw 71 | 4 studs |
| LDraw 378 | 3 studs |
| LDraw 78 | 2 studs |
| LDraw 26 | 1 studs |
| role | provider / dataset | date | license · attribution |
|---|---|---|---|
| elevation | USGS 3DEP 3DEPElevation (Bare Earth DEM Dynamic) | None | Public domain USGS 3D Elevation Program (3DEP) |
| imagery | USGS The National Map USGSNAIPPlus (NAIP, latest mosaic) | 2022-04-28 | Public domain USDA FSA NAIP via USGS The National Map |
| PASS | coverage_complete | non-finite DEM px: 0; non-finite imagery px: 0 |
| PASS | dem_imagery_aligned | 2 grids share bounds EPSG:26905; max extent mismatch 0.000 m |
| PASS | every_stud_has_elevation | 65536 studs |
| PASS | every_stud_has_allowed_color | all colors in catalog |
| PASS | no_terrain_below_datum | min plates per exaggeration: {'x3.0': 0} |
| PASS | quant_error_within_half_plate | max |error| plates: {'x3.0': 0.5} |
| PASS | catalog_colors_currently_produced | 20 colors used; not currently produced: [] |
| PASS | terrain_colors_plate_buildable | every used color is produced as a 1x1 plate |
| FAIL | summit_position | DEM max in stud (40, 141); highest stud (42, 138); offset 3 stud(s) |
| PASS | exaggeration_invariance | 1 exaggerations share footprint [(256, 256)] and one color array per color setting (colors are computed independently of exaggeration) |
| PASS | viewer_written | 1 whole-mountain 3D viewer(s) |
| PASS | ldraw_valid:x3.0_naip_average_diffusion0.10 | 171350 elements checked |
| PASS | ldraw_seams:x3.0_naip_average_diffusion0.10 | module files together equal the full model |
{
